| Brand Name: | Sinotruk HOWO |
| Model Number: | CLW |
| MOQ: | 1 |
| Price: | 15000-35000 per unit |
| Payment Terms: | 50% Deposit,Balance should be paid before ship out |
| Supply Ability: | 10unit per month |
Equipped with a dedicated water pump for efficient water distribution and self-suction.
Includes features like a fire valve, water valve, filter gauze, and a self-suction function for drawing water from sources like ponds or rivers.
Tank volume is 3-30M3, watering tank with pump, when water truck is transporting drinking water, inner face must make anti-corrosive paint.
Water tank truck is used for garden environment-keeping, Municipal maintains, area virescence, road building, large government department transporting drinking water.
| Feature | Typical Range/Value | Notes |
| Driving Type | 4x2 | 6-wheeler (two axles) |
| Tank Capacity | 10,000 Liters (10m3) | May also be referred to as 10 tons |
| Engine | Sinotruk WD615 series (e.g., WD615.62, WD615.87) | Diesel, 4-stroke, 6-cylinder in-line, water-cooled, turbo-charged |
| Horsepower (HP) | 266 HP to 290 HP (approximate) | Varies based on engine model and emission standard |
| Emission Standard | Often Euro II or Euro III | Depends on the target market and year of manufacture |
| Gearbox | Manual, typically 10 forwards and 2 reverse speeds | Sinotruk HW series (e.g., HW13710) |
| Cab | HOWO HW76 Long Cab | Typically with one sleeper bed and air conditioning (A/C) |
| Tires | 12.00R20 or 12R22.5 radial tires | Includes one spare tire |
| Max Speed | Around 90 km/h | |
| Tank Material | High-quality Carbon Steel (e.g., Q235) | Thickness typically around 4-5mm |
| Products Technical Specification | |
| Model | SCS5160GSSZZ4 |
| Brand | SINOTRUK chassis |
| Cab | 2080 mm width, single cabin with a sleeper |
| Vehicle Description | |
| Overall dimensions(mm) | 8400*2420*2750 |
| Effective tank volume | 10000L |
| Max speed (Km/h) | 110 |
| Engine Description | |
| Engine model | YC4E160-33 |
| Maximum power | 118kw / 160hp |
| Displacement (lit) | 4260 |
| Engine Manufacturer | Yuchai |
| Chassis Description | |
| Chassis model | ZZ1167G4715C1 |
| Wheel base | 4700 |
| F/R track base(mm) | 1680/1650 |
| F/R overhang(mm) | 1110/2345 |
| Spring plate | 8/10+6 |
| Front axle / rear axle | 5850/9945kgs |
| Gear box | MLD 6-speed with over drive |
| Brake system | oil braking |
| Operation control system | Power Steering |
| Electric system | 24V |
| Tyres | 9.00R20 |
| Feature | Typical Specification Range |
| Tank Volume | 10,000 Liters (10m³) |
| Tank Material | High-quality Carbon Steel (e.g., Q235A), with ≈4 to 5 mm thickness |
| Water Pump | High-quality self-priming sprinkler pump (driven by PTO) |
| Flow Rate (Pump) | ≈60 m3/h (varies) |
| Self-Suction Height | ≤7m (or ≈7.5m) |
| Sprinkling Functions | Front flushing/spraying (duck-shaped or punch nozzles) |
| Rear sprinkling/spraying (cylindrical or shower nozzles) | |
| Side spraying | |
| Rear working platform with High-pressure water cannon/gun | |
| Sprinkling Width | ≥14 to 20 meters |
| Water Cannon Range (Vertical/Column) | ≥28 to 30 meters |
| Other Equipment | Fire fighting interface/valve, water valve, filter gauze, manhole for access, ladder, water level gauge |
| Feature | Typical Specification Range |
| Overall Dimensions (L×W×H) | Varies, e.g., ≈8377×2496×3048 mm or similar |
| Wheelbase | Varies, e.g., ≈4600 mm |
| Gross Vehicle Weight (GVW) | ≈16,000 kg (Varies based on configuration and regulations) |
| Curb/Tare Weight | ≈7,800−9,200 kg |
| Payload Capacity | ≈8,000−10,000 kg |
Establishment: Founded in September 2004.
Headquarters: Located in Suizhou City, Hubei Province, which is known as the "capital of China's special purpose vehicles."
Role: It is a large-scale manufacturer designated by the Chinese government for various types of special vehicles. The CLW Group is one of China's Top 500 Private Enterprises and a diversified group company.
Scale: The company has a large production capacity, extensive facilities, and a significant number of employees.
Established in Sep. 2004,Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14 millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).
The products that form the core of their export business often include:
Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in Asia, Africa, South America, middle east and so on, such as Russia, Mongolia, Philippines, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, Uzbekistan, Kyrghzstan, Tanzania, Zambia, Nigeria, Australia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina and also truck body for client drawing
