| Brand Name: | CLW |
| Model Number: | CLW |
| MOQ: | 1 |
| Price: | 15000-35000 per unit |
| Payment Terms: | 50% Deposit,Balance should be paid before ship out |
| Supply Ability: | 10unit per month |
Chassis and Drive:
Chassis: SINOTRUK HOWO series (a popular heavy-duty chassis).
Drive Type: 8x4 (8 total wheels/points of contact with the ground, with 4 wheels driven). This configuration gives it good load-carrying capacity and traction.
Wheels: Typically 12 wheels (including a dual tire setup on the rear axles).
Engine: Powerful diesel engine, often from brands like WEICHAI or SINOTRUK, with horsepower ranging (e.g., 336 HP to over 370 HP).
Cab: Crew-cab design to accommodate several firefighters (e.g., 2+4 or 3 persons).
Fire Fighting & Rescue Specifications:
Function: Combines large-capacity water and foam tanks for extinguishing fires, along with equipment for general fire and rescue operations.
Tank Capacity: These are large volume trucks. Typical capacities can be:
Tank material is commonly carbon steel, with stainless steel or PP material as an option.
Fire Pump: Equipped with a high-flow fire pump, often rated for 60 L/s or more, with a rated pressure (e.g., 1.0 MPa).
Fire Monitor (Cannon): Mounted on the roof, capable of delivering long-range water and foam jets (e.g., water reach ≥45m to 70m, foam reach ≥40m to 60m).
Foam System: Includes a foam proportional mixing system.
Equipment: The truck includes equipment compartments for fire hoses, nozzles, couplings, axes, cutting equipment, rescue tools, and other essential firefighting gear.
Applications:
The large water and foam capacity of the 8X4 configuration makes it ideal for:
HOWO 12 Wheels 8X4 Water Rescue Tank Foam Fire Engine Fighting Truck can vary depending on the specific manufacturer, model, and configuration (e.g., tank size, pump type, rescue equipment). However, based on common offerings for this type of heavy-duty fire truck (Sinotruk HOWO 8X4), here is a compilation of likely technical specifications:
| Chassis and Engine | ||
| Specification | Typical Range / Example | Notes |
|---|---|---|
| Chassis Brand | Sinotruk HOWO (or specific series like A7, T5G) | A heavy-duty, 8x4 drive configuration (12 wheels). |
| Driving Type | 8x4 | 4 axles, 4 driven wheels. |
| Cab Type | Double Row/Crew Cab (4 doors) | Accommodates 2+3, 2+4, or more crew. |
| Engine Model | Sinotruk/Weichai Diesel (e.g., WP12 series) | |
| Engine Power | 375 HP - 420 HP (or higher) | (276 kW - 309 kW) |
| Emission Standard | Euro II, Euro III, or higher (e.g., Euro V) | Varies by sales region and model year. |
| Max. Speed | Approx. 90 - 110 km/h | |
| Wheelbase | Typically around 1800+4600+1350 mm | Varies based on total length. |
| Tire Specification | E.g., 11.00R20 or 315/80R22.5 | 12 tires + 1 spare. |
| Item | Details |
|---|---|
| Chassis Brand | Sinotruk HOWO |
| Drive Type | 8×4 (12 wheels) |
| Cabin | 4-door double row, 6 crew capacity |
| Engine Power | 336 HP / 371 HP (optional: WP10.340E32, WD615.47) |
| Emission Standard | Euro II / Euro III |
| Gearbox | 10-speed manual transmission |
| Overall Dimensions | Approx. 11,000 × 2500 × 3600 mm |
| GVW (Gross Vehicle Weight) | ~31,000 kg |
| Max Speed | 90 km/h |
The Sinotruk HOWO 336hp Fire Fighting Truck with a 10,000-liter water tank and a 2,000-liter foam tank is a heavy-duty, versatile fire-suppression vehicle designed for significant and specialized fires. Its main applications include:
Industrial and Petrochemical Fires: The large foam capacity (2,000 liters) makes it ideal for fighting Class B fires, which involve flammable liquids like oil, gasoline, and chemicals. These types of fires are common in:
General Large-Scale Fires: The massive 10,000-liter water capacity allows it to combat large structure fires and general material fires (Class A fires) for an extended period without immediately needing to refill. Applications include:
Ports and Docks: These environments often involve large volumes of flammable goods and are critical infrastructure, making the truck suitable for:
Public Security and Municipal Fire Brigades: It serves as a powerful, high-capacity vehicle for city and local fire departments to tackle major incidents that exceed the capacity of smaller, standard fire engines.
Chengli Special Automobile Co., Ltd. (part of the CLW Group) is a major Chinese manufacturer specializing in a vast range of special purpose vehicles. It is one of the largest and most comprehensive special vehicle production enterprises in China
Established in Sep. 2004,Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14 millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).
Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in
Asia, Africa, South America, middle east and so on, such as Russia, Mogolia, Philippine, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, uzbickstan, Kyrghyzstan, Tanzania, Zambia, Nigeria, Austrilia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina and so on.
